Mechanical Specifications
|
Dimensions
|
127 mm x 90 mm x 41 mm (L x W x H)
|
|
Weight
|
200 g
|
|
Mating Connector
|
18 pin female (right angle and straight through options)
|
Power Parameters
|
Input Voltage
|
7 to 40 V
|
|
Load Dump
|
SAE J1455 Section 4.13.2.2.1
|
Interfaces
|
BLE, CANBus, and USB Interfaces
|
|
|
(2) x Analog or Digital Output
|
|
|
(2) x Digital Input or Output
|
|
Internal Sensors
|
Accelerometer
|
|
|
Temperature Sensor
|
|
|
GPS/GLONASS/Galileo/Beidou
|
|
Environmental Specifications
|
Storage Temperature
|
-40 C to 85 C
|
|
Operating Temperature
|
-40 C to 70 C
|
|
Operational Vibration
|
SAE J1455 Section 4.10
|
|
Shock
|
1 m drop test as per SAE J1455
|
|
Salt Spray
|
SAE J1455 Section 4.3.3.1
|
|
Low Pressure Storage
|
30,000 feet
|
|
Humidity
|
SAE J1455 Section 4.2.3
|
|
Ingress Protection
|
IP67
|
|
Splash Testing
|
SAE J1455 Section 4.4.3.2
|
|
Steam and Pressure Washing
|
SAE J1455 Section 4.5.3
|
Regulatory Standards and Compliance
US (FCC), EU (CU MARK), Canada (IC), ROHS IEC 60945
C1D2 Groups A, B, C, D certification to ANSI/ISA 12.12.01-2011
