Explorer 710
Cobham Explorer 710 Portable Inmarsat BGAN Terminal
The all-new EXPLORER 710 provides on-demand streaming rates at 650 kbps out of the box. As the world's smallest Class 1 BGAN terminal and the first to take advantage of Inmarsat's new streaming service (High Data Rate), the EXPLORER 710 will deliver high-speed, ultra-portable satellite streaming for broadcasting and other IP-based industry applications. The EXPLORER 710 includes several advanced new features, including plug and play bonding - simply connect two EXPLORER 710's and double the throughput. A low-end VSAT capability in a portable BGAN form factor.
- An ultra-portable satellite terminal set to usher in a new era in the world of BGAN by setting new standards for size, speed and features.
- The smallest Class 1 BGAN terminal positioned to support broadcasters in enhancing the quality of mobile outside broadcasting.
- The new flagship in the EXPLORER series introduces Smart Phones to the world of BGAN, enabling users to connect their own devices for controlling the terminal and for voice calling and connectivity.
- The first BGAN terminal to support the new High Data Rate on-demand streaming service from Inmarsat. With speeds higher than 600 kbps the EXPLORER 710 sets a new standard for mobile video newsgathering. Double the speed with plug and play bonding - achieve streaming rates over 1 Mbps.
- USB host interface, hot-swappable batteries, a large easy-to-use LED display and multiple interfaces to support a wide range of applications
Unique possibilities:
Continuing the tradition of technology leadership started when the EXPLORER team introduced its first BGAN terminal in 2005, EXPLORER 710 introduces several advanced new features. Uniquely, it has the ability to bond the signals from multiple EXPLORER 710 terminals via Ethernet to achieve IP streaming rates of 1 Mbps or even higher - closer to standard definition broadcast quality.
Bring your own device:
EXPLORER 710 also introduces Smart Phone apps to the world of BGAN connectivity, enabling users to wirelessly connect their own devices for voice calling and connectivity. It's light, compact, tough and incredibly reliable. It opens more possibilities for connecting devices, offering more flexibility. It's ultra-portable, so you can be set-up within minutes of arriving on scene.
EXPLORER Connect App
Use your smartphone / tablet to connect, monitor, control the terminal as well as turning your smartphone into a satellite phone. Make and receive calls from anyone. Download the iPhone or Android app. Make calls simultaneously with an Internet connection. Does not degrade Internet service since calls are connecting with a different "regional" beam.
For GSA pricing, please go to GSA Advantage.
Specifications
- 332 / 279 / 54 mm
- 13.07 / 10.98 / 2.13 inches
Total weight:
- 3.5 kg / 7.7 lbs (incl. battery)
Antenna:
- 1.9 kg / 4.2 lbs
Transceiver (incl. battery):
- 1.6 kg / 3.5 lbs
Global Services
Voice:
- 4 kbps AMBE+2
Premium voice:
- 3.1 kHz audio, 64 kbps
Standard IP:
- Up to 492 kbps
Streaming IP:
- 32, 64, 128 kbps (256 kbps & BGAN X-Stream)
High Data Rate Streaming:
- Min. 600 kbps Min. 300 kbps (Half-channel HDR)
ISDN:
- UDI 64 kbps / RDI 56 kbps
SMS:
- Supported
Inmarsat frequencies:
- 1518.0 - 1525.0 MHz (Rx) (EMEA) 1525.0 - 1559.0 MHz (Rx) 1626.5 - 1660.5 MHz (Tx) 1668.0 - 1675.0 MHz (Tx) (EMEA)
EIRP:
- 20dBW ±1dB
