Mechanical Specifications
|
Dimensions
|
164.2 mm x 71.2 mm x 32.9 mm (L x W x H)
|
|
Weight
|
~470 g
|
Environmental Specifications
|
Operating Temperature
|
-40 C to 85 C
|
|
High Temperature Resistance
|
MIL -STD-810G:501.5, IEC60068-2-2 to 85 C
|
|
Low Temperature Resistance
|
MIL -STD-810G:502.5, IEC60068-2-1 to -50 C
|
|
Recommend Storage Temperature
|
Store below 32 C for best results
|
|
Combined Thermal and Humidity Exposure
|
MIL -STD-810G:507.5, 20-90%RH up to 60 C
|
|
Solar Radiation Exposure
|
UL746C F1, ASTM-G154 to 1.0 yr
|
|
Salt Fog Exposure
|
MIL-STD-810G;509.5 IEC60068-2-11 to 1000 hrs
|
|
Combined Operational Temperature and Altitude
|
MIL-STD-810G:500.6 to 15000 ft
|
|
Thermal Shock
|
MIL-STD-810G:503.5 20 cycles between -40 C to 85 C <1 min="" transition="" p="">
|
|
Impact Resistance
|
ASTM D3763
|
|
Operational Vibration
|
MIL-STD-810G:514.7, IEC60068-2-80 to 7.5Grms Random (5Hz-2000Hz)
|
|
HALT
|
Qualmark HALT testing guideline 993-0336, Rev 4 to 50Grms (5Hz – 10000 Hz, -40 C to 85 C)
|
|
Mechanical Shock
|
MIL-STD-810G:516.7 to 300Gpk
|
|
Reliability
|
IPC9592a
|
|
Ingress Protection
|
IP68
|
Certifications Available on Product Launch
|
FCC
|
Part 15, Part 25
|
|
Industry Canada
|
RSS-210, 247, ICES-003 Class B
|
|
EU
|
RED Directive 2014/53/EU, RoHS Directive 2011/65/EU, REACH Regulation EC 1907
|
Certifications Available Shortly After Product Launch
|
Brazil
|
ANATEL Ato N⁰ 1120, Resolucão N⁰ 680 e Ato N⁰ 14448
|
|
Australia/New Zealand
|
RCM – CISPR22
|
|
Mexico
|
IFT, NOM121
|
|
CB Ordinary Locations
|
IEC/EN 60950-1, EIC/EN 60950-22
|
|
OSHA Ordinary Locations Safety
|
ANSI/UL 60950-1, 60950-22
|
